slotted hole perforated metal/slotted hole perforated sheet/slotted hole perforated sheets

Short Description:

Send email to us

Product Detail

Product Tags

Overview

Quick Details

Place of Origin:: Hebei, China

Material:: STAINLESS STEEL WIRE

Type:: Perforated Mesh

Application:: Protecting Mesh

Weave Style:: Plain Weave

Technique:: Perforated

Model Number:: YND–perforated metal

Brand Name:: YND

rectangular hole perforated metal ,slotted hole perforated metal,perforated metal

Certification	ISO9001:2008
plate thickness	0.4-6.0mm
hole size	1.8-25mm
Pitch	3-34mm
staggered angle	45,60,90
Opening rate	23%-49%
Price	Negotiable
Packaging Details	in pallets

1.Material:stainless steel plate,galvanized plate,copper plate,steel plate,aluminum plate
2.Surface treatment:electro galvanized,hot-dipped galvanized,PVC coated,powder coated.
3. specification of Slotted Hole Perforated metal:

Opening (mm)	Center type(mm)	Thickness of sheet(mm) min-max	Size (mm)	Stainless Steel	Iron	Aluminium
2×10	≥3	0.4—2	1220×2440	√	√	√
2×15	≥3	0.4-2	1220×2440	√	√	√
2×20	≥3.5	0.4-2	1220×2440	√	√	√
1.5×15	≥3.5	0.4-2	1220×2440	√	√	√
3×10	≥4	0.4—2.5	1220×2440	√	√	√
2.5×10	≥3.5	0.4—2.5	1220×2440	√	√	√
3.5×10	≥4.5	0.4-3	1220×2440	√	√	√
4×5-25	≥5	0.4-3.5	1220×2440	√	√	√
5×5-25	≥6.5	0.4–4	1220×2440	√	√	√
10×10	≥12	0.5–4	1220×2440	√	√	√
12×15	≥14	0.5-4	1220×2440	√	√	√
15×16	≥18	0..6–4	1220×2440	√	√	√
20×20	≥23	0.8—4.5	1220×2440	√	√	√
22×23	2≥5	0.8—4.5	1220×2440	√	√	√
Above specifications for reference only,specifications can be customized according to user needs.

4.characteristics:

1>.various kind of hole patterns.

2>.accurate hole s,bending resistance,corrosion resistance.

3>.easy to process and install,good sound absorption

4>.Durable and long service life.

5>.attractive appearance and wide range of thickness available.

5.application:

Perforated metal is widely used in filter of automobiles internal-combustion engine, sieving of mine, medicine, grain, sound insulation of room, ventilate of grain depot, etc.
